TYAN S7002 - Page 15

http://www.TYAN.com
15
standard
Connector
type
D-Sub 15pin
Resolution 1600x1200@60Hz
Graphic
Chipset Aspeed AST2050
USB (8) USB2.0 ports (4 at rear, 4 via cable)
COM (2) ports (1 at rear, 1 via cable)
VGA (1) D-Sub 15pin VGA port
RJ-45 (2) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / EPS 12V
Front Panel (1) 2x12 pin SSI Front Panel header
Input /Output
SATA (6) SATAII connectors
Chipset Winbond W83793G
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (5) 4-pin headers
Temperature Monitors temperature for CPU & system environment
LED
Fan fail LED indicator / Over temperature warning
indicator
System
Monitoring
Others Chassis intrusion detection / Watch Dog timer support
Onboard
Chipset
Onboard Aspeed AST2050
AST2050 IPMI
Feature
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote platform-
flash/ BIOS update / USB 2.0 virtual Hub
Server
Management
Server
Management
AST2050
iKVM Feature
24bit High quality video compression / Dual 10/100 Mb/s
MAC interfaces
Brand / ROM
size
16MB / AMI
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE
Boot / ACPI 2.0 power management /Power on mode
after power recovery / Auto-configurable of hard disk
types / Multiple boot options
Form Factor SSI CEB
Form Factor
Board
Dimension
12"x10.5" (305x267mm)
