Tyco FASTFLEX YN25 Assembly

TFP720
Page 3 of 8
HOSE ASSEMBLIES
BAR FIXING CLAMPS
SPRINKLER REDUCERS
MALE HOSE
OUTLET
STRAIGHT
AND BRACKET
120 mm
THREADED
25 or 28 mm ID
INLET
or 3/4" NPT
1/2" NPT,
ISO 7-Rc 3/8,
FEMALE PIPE
THREADED
WRENCH
FLATS
BRANCHLINE
FITTING
TERMINATION
FERRULE
SPRINKLER
REDUCER
HOSE
FLEXIBLE
HOSE
NIPPLE
INLET
120 mm
45 DEGREE
125 mm
125 mm
90 DEGREE
133 mm
L1
L2
NUT
SLIP
FLATS
WRENCH
AND BRACKET
25 or 28 mm ID
THREADED
MALE HOSE
INLET
OUTLET
THREADED
FEMALE PIPE
1/2" NPT,
or 3/4" NPT
ISO 7-Rc 3/8,
ISO 7-Rc 3/8,
FEMALE PIPE
THREADED
or 3/4" NPT
OUTLET
1/2" NPT,
WRENCH
AND BRACKET
FLATS
INLET
25 or 28 mm ID
THREADED
MALE HOSE
50 mm
90 mm
90 DEGREE SHORT RADIUS
(LPCB APPROVED APPLICATIONS ONLY)
68,5 mm
OUTLET
FEMALE PIPE
THREADED
1/2" NPT
WRENCH
FLATS
AND BRACKET
37 mm
MALE HOSE
THREADED
25 or 28 mm ID
INLET
MODEL
SIZE
NOMINAL LENGTH mm
L1
(YN or YB)
L2
(YN)
L2
(YB)
700 580 390 370
1000 880 690 670
1200 1080 890 870
1500 1380 1190 1380
1800 1680 1490 1470
2000 1880 1690 1670
2500 2380 2190 2170
2700 2580 2390 2370
3100 2980 2790 2770
3700 3580 3390 3370
FIGURE 2
FASTFLEX FLEXIBLE SPRINKLER HOSE
NOMINAL DIMENSIONS
