TFP720
Page 4 of 8
UL - Design Criteria
•
Refer to Table A for Model, Nominal Assembly Length,
and Sprinkler Reducer combinations
• Wet-pipe systems only
•
The hose and ttings have limited exibility and are
intended for direct connection to sprinklers in accor-
dance with NFPA 13, 13D, or 13R
• Maximum service pressure of 13 bar
•
Maximum K80 (5.6K) for 1/2 inch NPT sprinklers or
maximum K160 (11.2K) for 3/4 inch NPT sprinklers
•
Maximum ambient temperature of 107°C for Model
YB25 and YB28, or maximum ambient temperature of
148°C for Model YN25
•
These connections are designed for use in ceilings
with grids that meet ASTM C 635 (Standard Specifi-
cation for the Manufacture, Performance, and Testing
of Metal Suspension Systems for Acoustical Tile and
Lay-in Panel Ceilings) and ASTM C 636 (Standard
Practice for Installation of Metal Ceiling Suspension
Systems for Acoustical Tile and Lay-in Panels) refer-
enced by IBC. The three structural classications are
the following: Intermediate-Duty Systems and Heavy-
Duty Systems. These connections have been approved
for use in all Intermediate-Duty and Heavy-Duty struc-
tural classications
• Minimum bend radius of 76 mm
• UL Friction Loss:
Assembly
Length
in
millimeters
Outlet
(NPT)
Max.
Number
of 90°
Bends*
YN25
and
YB25
YB28
Equivalent
Length
of DN25
Sch. 40 Pipe
C=120
in meters
Equivalent
Length
of DN25
Sch. 40 Pipe
C=120
in meters
700
1/2 2 6,7 3,0
3/4 2 8,5 4,9
1000
1/2 2 9,8 4,9
3/4 2 11,6 7,0
1200
1/2 2 12,5 6,1
3/4 2 14,6 7,6
1500
1/2 2 14,9 7,0
3/4 2 16,5 8,5
1800
1/2
2 18,3 7,9
3 20,4 9,8
3/4
2 20,4 10,1
3 22,6 11,6
* Information in this column indicates the maximum number of allowable bends and
that hoses are installed with at least one bend.
FM - Design Criteria
•
Refer to Table A for Model, Nominal Assembly Length,
and Sprinkler Reducer combinations
• Wet pipe, preaction, and dry pipe systems
• Maximum service pressure of 12 bar
•
Maximum K80 (5.6K) for 1/2 inch NPT sprinklers or
maximum K115 (8.0K) for 3/4 inch NPT sprinklers
•
Maximum ambient temperature of 107°C for Model
YB25 and YB28
•
Minimum ambient temperature of -40°C for Model
YB25 and YB28 for use in dry pipe systems
•
These connections are designed for use in ceilings
with grids that meet ASTM C 635 (Standard Specifi-
cation for the Manufacture, Performance, and Testing
of Metal Suspension Systems for Acoustical Tile and
Lay-in Panel Ceilings) and ASTM C 636 (Standard
Practice for Installation of Metal Ceiling Suspension
Systems for Acoustical Tile and Lay-in Panels) refer-
enced by IBC. The three structural classications are
the following: Intermediate-Duty Systems and Heavy-
Duty Systems. These connections have been approved
for use in all Intermediate-Duty and Heavy-Duty struc-
tural classications
•
Minimum bend radius of 152 mm for Model YB28 or
203 mm for Model YB25
• FM Friction Loss for YB25 and YB28:
Assembly
Length
in
millimeters
Outlet
(NPT)
Max.
Number
of 90°
Bends
YB25 YB28
Equivalent
Length
of DN25
Sch. 40 Pipe
C=120
in meters
Equivalent
Length
of DN25
Sch. 40 Pipe
C=120
in meters
700 1/2 1 14,1 7,7
3/4 1 11,9 6,0
1000 1/2 1 16,4 12,2
3/4 1 13,8 10,4
1200 1/2 2 22,4 15,2
3/4 2 19,6 13,4
1500 1/2 3 27, 4 17,6
3/4 3 26,4 16,1
1800 1/2 4 34,4 20,0
3/4 4 32,0 18,7
