Tyco FP1600 User Manual

LT0312 v1.03 4 July 2003
Page 13
Programming Flowchart
= SELECT pushbutton
= MODE pushbutton
= CHANGE pushbutton
Latch
togglestogglestogglestogglestogglestogglestogglestogglestogglestogglestoggles
ON by
Evacuation
Switch ?
OFF by
Silence
Alarms ?
OFF by
Services
Restore ?
ON by
Lamp
Test ?
Follow
Evacuation
(Bells) Relay ?
Follow
Common
Fire ?
Follow
Common
Defect ?
Follow
Common
Normal ?
Follow
Panel
Reset ?
Follow
Charger
Inhibit ?
Centre decimal on = yes
Press
to step
thru all
Ancillaries
toggles
Brigade
Connected
or Local only
Evacuation
Supervision
enable/disable
toggles toggles
Ancillary
Override
enable/disable
Flowswitch Delay
steps steps
Battery Low
Voltage Adj.
steps steps steps
Residential
Delay
Number of
RDZUs
x10 seconds
0 = latch
No. of RZDUs
= 1- 8
0 = none
No. of boards
in System
1- 8 (Master)
0 to disable
on Slave
Number of
boards in
System
Reload
defaults
Save values
and exit
Press SELECT to step
through Ancillaries to map
from Universal Variables
Press MODE to
step through
Universal Variables
Press CHANGE to change mapping.
Centre decimal on = yes
Press MODE to step to
next Universal Variable
Press SELECT to step
through Groups to map
to Ancillaries
Press MODE to step
through Ancillaries
Press CHANGE to change mapping.
Centre decimal on = yes
Press MODE to step to
next Ancillary
Press SELECT to step
through Groups to map
to Universal Variables
Press MODE to
step through
Universal Variables
Press MODE to step to
next Universal Variable
Press CHANGE to change mapping.
Centre decimal on = yes
