Ordering Information - Panels and Accessories
Programming Groups - A programming Group exists within a board only and becomes active only when
all zones on that board mapped to the group are in alarm and not isolated. Groups can optionally be
latching (until panel reset) and can be mapped to ancillary outputs and/or universal variables.
(For residential circuit types, any activated alarm type mapped to a group is sufficient).
Universal Variables - Programming Universal Variables (U01-U16) can be driven and accessed by all
boards in the system, and allow some logical OR combinations of zone and group statuses between
boards. Universal Variables can be mapped to ancillary outputs.
Ancillary Override (System configuration option) - If Ancillary Override is enabled, “Door Open” is
treated the same as operating the Services Restore switch.
Ancillary Output Programming - Ancillary outputs follow a logical OR of the options selected, except
for overrides required by standards (eg. Evacuation overrides Silence Alarms)
Door Switch Supervision - (Master board only, not optional) When fitting a Mk3 Master board into an
older cabinet, solder a 220kW 1% resistor across the Services Restore switch terminals.
Earth Fault Monitoring - Detects a leakage from field wiring to earth. This facility can be disabled by
cutting out link R65 on all Mk3 boards in the system.
LT0312 v1.03 4 July 2003
Page 5
OMEGA 64 Masters have only 16 zones fitted. Extenders have no zone boards fitted.
Refer to LT0200 - "How to order FP1600 and OMEGA64" for more detailed information.
FP0547
FP0700
FP0640
PA0977
FA1371
FA1379
FP0548
FP0701
FP0641
KT0215
LM0074
KT0131
PA0702
LM0046
LM0049
LT0196
LT0312
RR0753
FA1372
FA1380
FA1209
PA0862
HW0036
FP1600 Rear Service
OMEGA 64 R/S Master (32 Zone index)
OMEGA 64 R/S Extender (16 Zone index)
OMEGA 64 Mk3 R/S Slave Board
OMEGA 64 R/S 32 Zone Master Index
OMEGA 64 R/S 16 Zone Extender Index
FP1600 Front Service
OMEGA 64 F/S Master (32 Zone index)
OMEGA 64 F/S Extender (16 Zone index)
OMEGA 64 Mk3 F/S Slave Board Set
OMEGA 64 Master to 1st Slave Loom
OMEGA 64 Comms Extender Kit for 2 or more Slaves
FP1600 16 Way Mimic Termination Board
I/O Board 26 Way Flat Ribbon Cable Loom (0.50m)
I/O Board 26 Way Flat Ribbon Cable Loom (0.25m)
FP1600/OMEGA 64 Technical Manual
FP1600/OMEGA 64 Installation/Configuration Manual
Circuit EOL Resistor (2k70 1%)
OMEGA 64 F/S 32 Zone Master Index
OMEGA 64 F/S 16 Zone Extender Index
FP1600 F/S Index FA1207 FP1600 R/S Index
GP SGD PA0861 GP Brigade Relay Interface
Door Key HW0213 Keyswitch Key
