PowerSeries Pro Installation Guide

Trouble 03 – Bus Voltage:

[01] HSM2HOSTx Bus Low Voltage: The HSM2HOSTx module has measured a low

bus voltage.

[02] Keypad 01 - 16 Bus Low Voltage: A hardwired keypad has a low bus voltage.

[04] HSM2108 01 - 30 Bus Low Voltage: A zone expander has a low bus voltage.

[05] HSM2300 01 - 04 Bus Low Voltage: A power supply has a low bus voltage.

[06] HSM2204 01 - 04 Bus Low Voltage: A high current output module has a low

bus voltage.

[07] Bus Fault (System): Panel Corbus Output voltage is too hight or too low.

[08] HSM2208 01 - 16 Bus Low Voltage: The low current output module has detected

a low voltage.

[09] HSM2955 Bus Low Voltage: The audio module has detected a low bus voltage.

[10] HSM3408 Bus Low Voltage: The 8 zone expander has detected a low bus

voltage.

[11] HSM3204CX Bus Low Voltage: The corbus repeater has detected a low bus

voltage.

[12] HSM3204CX Bus Fault: The corbus repeater has detected that the corbus output

voltage is too high or too low.

[13] HSM3350 Bus Low Voltage: The 3 A power supply module has detected a low

bus voltage.

Trouble 04 – AC or DC input power trouble:

[01] Zone 001 - 248 AC or DC input power trouble.

[02] Keypad AC or DC input power trouble: A keypad has an AC or DC input power

trouble.

[03] Siren 01 - 16 AC: A siren has an AC or DC input power trouble.

[04] Repeater 01 - 08 AC: A wireless repeater has an AC or DC input power trouble.

[05] HSM2300 01 - 04 AC: An HSM2300 has an AC or DC input power trouble.

[06] HSM2204 01 - 04 AC: An HSM2204 has an AC or DC input power trouble.

[07] Panel AC: The alarm controller has an AC failure condition.

[08] HSM3204CX AC: A corbus repeater has an AC or DC input power trouble.

[09] HSM3350 AC: The 3A power supply has an AC or DC input power trouble.

Trouble 05 – Device Faults:

Note: Fire trouble is displayed directly under device faults when there is an open loop

condition for PGM-2 configured for 2-wire smoke.

[01] Zone 001 - 248: A zone is in supervisory fault.

[02] Keypad 01 - 16: A wireless or hardwired keypad is in supervisory fault.

[03] Siren 01 - 16: A siren is in supervisory fault.

[04] Repeater 01 - 08: A wireless repeater is in fault (supervisory or loss of AC/DC).

[06] Device Mask: A detection mechanism on the sensor is masked.

[07] Gas Trouble:A gas sensor is in fault.

[08] Heat Trouble: A temperature sensor is in fault or a temperature reaches the high

temperature warning threshold.

[09] CO Trouble: A CO sensor is in fault.

[10] Freeze Trouble: A temperature sensor falls below the low temperature warning

threshold.

[11] Probe Disconn.: The probe on the flood detector or the temperature detector is

disconnected.

[12] Fire Trouble: A smoke sensor is in fault.

Trouble 06 – Device Low Battery:

[01] Zone 001- 248: Wireless zone has a low battery.

[02] Keypad 01-16: Keypad has a low battery.

[03] Siren 01 - 16: Siren has a low battery.

[04] Repeater 01 - 08: Repeater has a low battery.

[05] User 01 - 1000: Wireless Key has a low battery.

Trouble 07 – Device Tampers:

[01] Zone 001 - 248 Tamper: A wireless or hardwired zone is in tamper.

[02] Siren 01 - 16 Tamper: A wireless siren is in tamper.

[03] Repeater 01 - 08 Tamper: A wireless repeater is in tamper.

[04] Audio Station 01 - 04 Tamper: An audio station connected to an HSM2955 is in

tamper.

Trouble 08 – RF Delinquency Trouble:

[01] Zone 001 - 248 RF Delinquency: No response from a wireless zone for 13

minutes. This trouble prevents arming until acknowledged or cleared using [*][2].

[02] Keypad 01 - 16 RF Delinquency: No response from a wireless keypad for 13

minutes.

[03] Siren 01 - 16 RF Delinquency: No response from a wireless siren for 13 minutes.

[04] Repeater 01 - 16 RF Delinquency: No response from a wireless repeater for 13

minutes.

Trouble 09 – Module Supervisory Trouble:

[01] HSM2HOSTx not responding.

[02] Keypad 01 - 16 not responding.

[04] HSM2108 01 - 30 not responding.

[05] HSM2300 01 - 04 not responding.

[06] HSM2204 01 - 04 not responding.

[08] HSM2208 01 - 16 not responding.

[09] HSM2955 is not responding.

[11] HSM3408 is not responding.

[12] HSM3204CX is not responding.

[13] HSM3350 is not responding.

Trouble 10 – Module Tamper:

[01] HSM2HOSTx Tamper.

[02] Keypad 01 - 16 Tamper.

[04] HSM2108 01 - 30 Tamper.

[05] HSM2300 01 - 04 Tamper.

[06] HSM2204 01 - 04 Tamper.

[08] HSM2208 01 - 16 Tamper.

[09] HSM2955 Tamper.

[10] Alt Comm Tamper.

[11] HSM3408 Tamper.

[12] HSM3204CX Tamper.

[13] HSM3350 Tamper.

Trouble 11 – Communications:

[01] TLM: Telephone line disconnected from control panel.

[02] Receiver 01-04 FTC Trouble: Failure to communicate using programmed receiver

paths.

[04] Alt. Comm Cellular: Radio or SIM card failure, low signal strength detected, or

cellular network fault.

[05] Alt. Comm Ethernet: Ethernet connection unavailable. A valid IP address is either

not programmed or the module was unable to get an IP with DHCP.

[06] Receiver 01-04 Trouble: Alternate communicator unable to initialize a receiver.

[07] Receiver 01-04 Supervision: Alternate communicator unable to communicate with

a receiver.

[09] Alt. Comm Fault: The alternate communicator has stopped responding.

[10] Alt Comm FTC Trouble: The alternate communicator has failed to communicate

an internal event not generated by the panel.

- 11 -
