PowerSeries Pro Installation Guide
8 – Reset After Zone Activation
020 System Options 8
1 – Access Code Entry During
Entry Delay
2 – EU Entry Procedure
3 – [*][8] Access While Armed
4 – Remote Reset
5 – Engineer's Reset
6 – Keyswitch Disarming During
Entry Delay
7 – Installer Access and DLS
8 – Troubles Inhibits Arming
021 System Options 9
1 – Trouble Display
2 – Keypad Blanking while armed
3 – Reserved
4 – Ready Display
5 – PGM Keypad Blanking
6 – Armed Display
7 – Open Cancels Arming
8 – Audible Exit Delay for Stay
Arming
022 System Options 10
1 – [F] Key Option
2 – Reserved
3 – Reserved
4 – Test Transmission Counter in
Hours
5 – Away to Stay Toggle
6 – 2-Way Full Duration
7 – Trouble Beeps Are Silent
8 – Keyswitch Arms in Away
Mode
023 System Options 11
1 – Ready LED Flash for Force
Arm
2 – Access Code Required for [*]
[*]
3 – Tamper/Fault Detection
4 – Access Code Required for [*]
[1]
5 – Access Code Required for [*]
[2]
6 – Access Code Required for [*]
[3]
7 – Access Code Required for [*]
[4]
8 – [*][6] Accessibility
024 System Options 12
1– Reserved
2 – Reserved
3 – AC/DC Inhibits Arming
4 – Tamper Inhibit Arm
5 – Real Time Clock
6 – Reserved
7 – Reserved
8 – DLS Disconnect
025 System Options 13
1 – European Dial
2 – Force Dial ✔
3 – Test Transmission Counter in
Minutes
4 – Warm Start Indication
5 – ID Tone
6 – Tone Generated-2100Hz
7 – DLS Window
8 – FTC Audible Bell
040 User Authentication
01 – User Code or Proximity Tag
✔
02 – User Code and Proximity Tag
041 Access Code Digits
00 – 4-Digit Access Codes ✔
01 – 6-Digit Access Codes
02 – 8-Digit Access Codes
042 Event Verification
01 – Burglary Verified Counter
(002)
02 – Holdup Counter (002)
03 – Burglary Verification
Selection
001 – Police Code ✔
002 – Cross Zoning
003 – EU Sequential
Detection
151-158 Partition 1-8 Auto-
Arm/Disarm
001 – Auto-Arming Times (9999)
24-Hour
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
002 – Auto-Disarm Times (9999)
24-Hour
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
003 – Auto-Disarming Holiday
Schedule
Holiday 1
Holiday 2
Holiday 3
Holiday 4
004 – Auto-Arming Pre-Alert
(004)
005 – Auto-Arming Postpone
Timer (000)
006 – No Activity Arming Timer
(000)
007 – No Activity Arming Pre-
Alert Timer (001)
200 Partition Mask
001 – Partition 1 to 8 Enable Mask
1 – Partition 1 ✔
2 – Partition 2
3 – Partition 3
4 – Partition 4
5 – Partition 5
6 – Partition 6
7 – Partition 7
8 – Partition 8
201-208 Partition 1-8 Zone
Assignment
001 – Zone 1-8 ✔
002 – Zn 9-16 ✔
003 – Zn 17-24
004 – Zn 25-32
005 – Zn 33-40
006 – Zn 41-48
007 – Zn 49-56
008 – Zn 57-64
009 – Zn 65-72
010 – Zn 73-80
011 – Zn 81-88
012 – Zn 89-96
013 – Zn 97-104
014 – Zn 105-112
015 – Zn 113-120
016 – Zn 121-128
017 – Zn 129-136
018 – Zn 137-144
019 – Zn 145-152
020 – Zn 153-160
021 – Zn 161-168
022 – Zn 169-176
023 – Zn 177-184
024 – Zn 185-192
025 – Zn 193-200
026 – Zn 201-208
027 – Zn 209-216
028 – Zn 217-224
029 – Zn 225-232
030 – Zn 233-240
031 – Zn 241-248
300 Panel/Receiver Communications
Path
001 – 004 Receiver 1-4
01 – Phone Line ✔
02 – Alt Comm Auto Routing
03 – Alt Comm Receiver 1 -
Ethernet 1
04 – Alt Comm Receiver 2 -
Ethernet 2
05 – Alt Comm Receiver 3 -
Cellular 1
06 – Alt Comm Receiver 4 -
Cellular 2
301 Phone Number Programming
001 – 004 Phone Number 1 -4
Programming (DFFF...32-digit)
304 Call Waiting Cancel String
(DB70EF)
Event Reporting
307 Zone Reporting
001-128 Zone Reporting for Zones
1-128
01 – Alarm ✔
02 – Alarm Restore ✔
03 – Tamper ✔
04 – Tamper Restore ✔
05 – Fault ✔
06 – Fault Restore ✔
308 Event Reporting
001 – Miscellaneous Alarm 1
01 – Duress Alarm ✔
02 – Opening After Alarm ✔
03 – Recent Closing Alarm ✔
04 – Zone Expander
Supervisory Alarm ✔
05 – Zone Expander
Supervisory Alarm Restore
✔
06 – Burglary Verified ✔
07 – Burg Not Verified Alarm
✔
08 – Alarm Cancel ✔
002 – Miscellaneous Alarm 2
01 – Holdup Verified Alarm
✔
011 – Priority Alarms
01 – Keypad Fire Alarm-F
Key ✔
02 – Keypad Fire Restore ✔
03 – Keypad Medical Alarm-
M Key ✔
04 – Keypad Medical Restore
✔
05 – Keypad Panic Alarm (P)
✔
06 – Keypad Panic Restore ✔
07 – Auxiliary Input Alarm
✔
08 – Aux Input Alarm Restore
✔
021 – Fire Alarms 1
03 – PGM 2 2-Wire Alarm ✔
04 – PGM 2 2-Wire Restore
✔
101 – Tamper Events
03 – Module Tamper ✔
04 – Module Tamper Restore
✔
05 – Keypad Lockout ✔
07 – Remote Lockout ✔
201 – Open/Close Events 1
01 – User Closing ✔
02 – User Opening ✔
03 – Future Use
04 – Future Use
05 – Special Closing ✔
06 – Special Opening ✔
07 – Keyswitch Opening ✔
08 – Keyswitch Closing ✔
202 – Open/Close Events 2
01 – Automatic Closing ✔
02 – Automatic Disarm ✔
03 – Auto Arm
Cancellation/Postpone ✔
211 – Miscellaneous Open/Close
Events
01 – Late to Close ✔
02 – Late to Open ✔
05 – Exit Fault ✔
221 – Bypass Events
01 – Auto Zone Bypass
02 – Auto Zone Unbypass
03 – Partial Closing ✔
301 – Panel Events 1
01 – Panel AC Fail Trouble
✔
02 – Panel AC Fail Restore
✔
03 – Panel Low Battery ✔
- 16 -
✔= Default
