PowerSeries Pro Installation Guide
020 – Time Zone
025 – Radio Activation Restore
026 – Receiver 1 Test
Transmission
027 – Receiver 2 Test
Transmission
028 – Receiver 3 Test
Transmission
029 – Receiver 4 Test
Transmission
030 – FTC Restore
095 – DLS SA Incoming Local
Port
096 – DLS SA Outgoing Local
Port
101 – Receiver 1 Account Code
102 – Receiver 1 DNIS
103 – Receiver 1 IP Address
104 – Receiver 1 UDP Remote
Port
105 – Receiver 1 UDP Local Port
106 – Receiver 1 Domain Name
111 – Receiver 2 Account Code
112 – Receiver 2 DNIS
113 – Receiver 2 IP Address
114 – Receiver 2 UDP Remote
Port
115 – Receiver 2 UDP Local Port
116 – Receiver 2 Domain Name
124 – Ethernet Test Transmission
Time
125 – Ethernet Test Transmission
Cycle
201 – Receiver 3 Account Code
202 – Receiver 3 DNIS
203 – Receiver 3 IP Address
204 – Receiver 3 UDP Remote
Port
205 – Receiver 3 UDP Local Port
206 – Receiver 3 Domain Name
211 – Receiver 4 Account Code
212 – Receiver 4 DNIS
214 – Receiver 4 UDP Remote
Port
215 – Receiver 4 UDP Local Port
216 – Receiver 4 Domain Name
221 – Cellular Public Access Point
Name
222 – Cellular Login User Name
223 – Cellular Login Password
224 – Cellular Test Transmission
Time of Day
225 – Cellular Test Transmission
Cycle
226 – Network Trouble Delay
227 – Voice Call Timeout
228 – Voice Call Back Time
229 – Voice Call Back Number
422 – Integration Identification
Number
423 – Session 1 Integration Access
Code
424 – Session 1 SMS Label
425 – Session 1 Integration Toggle
Options 2
01 – Integration Over USB
02 – Integration Over Cellular
03 – Integration Over
Ethernet
04 – Reserved
05 – Integration Protocol
06 – Reserved
07 – Reserved
08 – Reserved
426 – Session 1 Integration Toggle
Options 3
01 – UDP Polling
02 – TCP Polling
03 – Real-time Notification
04 – Notification Follows Pool
05 – Firewall IP
06 – Reserved
07 – Reserved
08 – Reserved
427 – Session 1 Interactive Polling
Interval
428 – Session 1 Integration Server
IP
429 – Session 1 Integration
Notification Port
430 – Session 1 Integration Polling
Port
431 – Session 1 Integration Server
DNS
432 – Session 1 Integration
Outgoing Port
433 – Session 1 Integration
Incoming Port
450 – 460 Repeats 423 - 433 for
Session 2
477 – 487 Repeats 423 - 433 for
Session 3
504 – 514 Repeats 423 - 433 for
Session 4
691 – Session 1 Notification
Control
01 – Alarm and Alarm
Restore Notifications ✔
02 – Tamper and Tamper
Restore Notifications ✔
03 – Arming and Disarming
Notifications ✔
04 – Trouble and Trouble
Restore Notifications ✔
05 – Test Transmission
Notifications ✔
06 – Reserved ✔
07 – Reserved ✔
08 – Reserved ✔
692 – Session 2 Notification
Control
01 – Alarm and Alarm
Restore Notifications ✔
02 – Tamper and Tamper
Restore Notifications ✔
03 – Arming and Disarming
Notifications ✔
04 – Trouble and Trouble
Restore Notifications ✔
05 – Test Transmission
Notifications ✔
06 – Reserved ✔
07 – Reserved ✔
08 – Reserved ✔
693 – Session 3 Notification
Control
01 – Alarm and Alarm
Restore Notifications ✔
02 – Tamper and Tamper
Restore Notifications ✔
03 – Arming and Disarming
Notifications ✔
04 – Trouble and Trouble
Restore Notifications ✔
05 – Test Transmission
Notifications ✔
06 – Reserved ✔
07 – Reserved ✔
08 – Reserved ✔
694 – Session 4 Notification
Control ✔
01 – Alarm and Alarm
Restore Notifications ✔
02 – Tamper and Tamper
Restore Notifications ✔
03 – Arming and Disarming
Notifications ✔
04 – Trouble and Trouble
Restore Notifications ✔
05 – Test Transmission
Notifications ✔
06 – Reserved ✔
07 – Reserved ✔
08 – Reserved ✔
901 – Receiver Test
01 – Receiver 1
02 – Receiver 2
03 – Receiver 3
04 – Receiver 4
976 – Configuration File Version
977 – Cellular NetworkProvider -
MCC/MNC Code
978 – Cellular Network Type
979 – Cellular Network CSQ
980 – Radio Reset Codes
981 – Radio Type
982 – Radio Firmware Version
983 – Firmware Update
Diagnostics Section
984 – Communicator Status
985 – Radio Initialization Status
986 – System Toggle Options 4
01 – Remote Shutdown Enable
Default
02 – 2-8 Reserved
987 – Language Version
988 – DNS 1 IP Address
989 – DNS 2 IP Address
990 – Boot Loader Version
991 – Firmware Version
992 – Ethernet IP Address
993 – Ethernet Gateway IP
Address
994 – Cellular IP Address
995 – SIM Number
996 – Cellular Telephone Number
997 – IMEI Number
998 – MAC Address
Keypad Programming
860 Keypad Slot Number
861-876 Keypad Programming
000 – Keypad Partition Mask
00 – Global Keypad
01 – Partition 1 ✔
02 – Partition 2
03 – Partition 3
04 – Partition 4
05 – Partition 5
06 – Partition 6
07 – Partition 7
08 – Partition 8
001 – Function Key 1 ()
002 – Function Key 2 ()
003 – Function Key 3 (06)
004 – Function Key 4 (22)
005 – Function Key 5 ()
00 – Null Key
02 – Instant Stay Arm
03 – Stay Arm
04 – Away Arm
05 – No Entry Arm
06 – Chime On/Off
07 – System Test
09 – Night Arm
12 – Global Stay Arm
13 – Global Away Arm
14 – Global Disarming
15 – Temperature
16 – Quick Exit
17 – Arm Interior
21-24 – Command Output 1-4
29 – Bypass Group Recall
31 – Local PGM Activate
32 – Bypass Mode
33 – Bypass recall
34 – User Programming
35 – User Functions
37 – Time/Date Programming
39 – Trouble Display
40 – Alarm Memory
61-68 – Partition Select 1-8
011 – Keypad I/O (000)
012 – Local PGM Output Timer
Pulse Time (00 minutes)
Pulse Time (05 sec.)
021 – Keypad Option 1
1 – [F] Key Enabled ✔
2 – [M] Key Enabled ✔
3 – [P] Key Enabled ✔
4 – Display Code or X's ✔
022 – Keypad Option 2
1 – Local Clock Display ✔
2 – Local Clock Display 24 Hour
3 – Auto Alarm Scroll ✔
5 – Power LED Option ✔
6 – Power LED AC Present ✔
7 – Alarms Displayed if Armed ✔
8 – Auto Scroll Open Zones ✔
023 – Keypad Option 3
1 – Armed LED Power Save*
2 – Keypad Show Arm Mode ✔ *
3 – 5th Terminal is PGM
Output/Zone
4 – Prox Tag Arm/Disarm
7 – Local Display of Temp.
8 – Low Temperature Warning
- 19 -
✔= Default
