Important
This installation manual shall be used in conjunction with the control panel installation manual available online
from the DSC website at www.dsc.com. All the safety instructions specified within that manual shall be
observed. The control panel is referenced as the “panel” throughout this document. This installation guide
provides the basic wiring, programming and troubleshooting information.
The alarm communicator is a fixed, wall-mounted unit, and shall be installed in the location specified in these
instructions. The equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs,
and secured to a wall before operation.
Safety instructions
Read the safety information before you install the equipment.
Important: This equipment must be installed by a skilled person only. A skilled person is an installer with
appropriate technical training. The installer must be aware of potential hazards during installation and
measures available to minimize risks to the installer and other people.
l Before you install this equipment, disconnect all power sources (for example mains, battery, and telephone
line) connected to the alarm panel.
l Install the equipment indoors in a non-hazardous environment where the following conditions are met:
o
Pollution degree - Maximum 2
o
Over voltages - Category II
l Internal wiring must be routed to prevent strain on wire and terminal connections, loose terminal
connections, and damage to conductor insulation.
l Instruct the user that there are no user serviceable parts in this equipment. All equipment must be serviced
by a skilled person.
Introduction
This guide provides installation and operating instructions for the Alarm.com communicator module. The
following sections offer you a brief overview of its capabilities. Some capabilities and features vary based on
the Alarm.com service plan selected. Visit www.alarm.com/Dealer or contact Alarm.com for more
information.
Note: The Dual Path IP/LTE module is available in the model TL880LE.
The module TL880LE contains the IP/Radio subassembly models ADC-620TE and the PC-Link to RS422
conversion interface. The module is compatible only with NEO Alarm Control Unit models HS2128, HS2064,
HS2032 and HS2016 software versions 1.1 and above.
The TL880LE Dual Path module enables wireless reporting of all alarms and other system events from the
DSC Neo control panel using an all-digital, LTE wireless (cellular) network or an Ethernet network. The
module can be used as the primary communication path for all alarm signaling, or as a backup to a telephone
connection to the central monitoring station. The wireless alarm signaling and routing service is operated by
Alarm.com. The module also features integrated support for Alarm.com’s home automation solution with
built-in Z-Wave capabilities.
Contact information
For additional information and support on Alarm.com modules, initial account setup, home automation, and all
other Alarm.com products and services, please visit: www.Alarm.com/dealer or contact Alarm.com technical
support at: 1-866-834-0470.
- 5 -
