Features
l 128-bit AES encryption via cellular and Internet.
l Model TL880LE has NIST validation certificate number 5100.
l Back up or primary cellular alarm communication and Ethernet.
l Remote firmware upgrade via cellular or Internet using Alarm.com management portal.
l Full event reporting to central station.
l Cellular periodic test transmission.
l Integrated call routing.
l Panel remote uploading/downloading support via cellular or Internet.
l PC-LINK connection.
l Programmable labels.
l SIA and Contact ID (CID) formats supported.
l Signal strength and trouble display LEDs.
l Subscriber Identity Module (SIM) card included with communicator.
l Supervision heartbeats over Ethernet path or over the Cellular path, when the Ethernet path is know to be
in a trouble condition.
l 2-way audio capable when used with audio module HSM2955(R).Refer to HSM2955 installation manual.
Communicator ratings
Model TL880LE
Power supply ratings
Input Voltage
11.3V - 12.5V DC
(provided by DSC NEO compatible control panel)
Current consumption
Standby Current (Average Value) 150mA
Alarm (Transmitting) Current (Peak
Value)
400mA
Cellular Network LTE AT&T
Operating Frequency 1700/1900 AWS700/850 MHz
Environmental specifications
Operating Temperature 32°F to 120°F (0°C to 49°C)
Storage Temperature -34°C to 60°C
Humidity 93%RH non-condensing
Mechanical specifications
Dimensions 6" x 8.9" x 1.3"
Weight 365g
