MID PTO
The speed of the mid PTO is 2,000rpm. Use the PTO lever to engage.
The PTO switch must be OFF before the PTO is engaged.
1. Decrease the engine speed to near idle.
2. Make sure that the PTO switch is OFF.
3. Engage the mid PTO using the PTO lever.
4. If the rear PTO needs to engage, shift the PTO lever to the correct position.
5. Turn on the PTO switch.
6. Increase the engine speed to a desired speed.
Caution
Do not operate any implement at a high speed than is specified.
When making adjustments to the implement, stop the engine to avoid serious
injury.
When leaving the tractor, stop the engine, remove the key, and set the parking
brake.
Important
If the operator turns off the PTO switch, the rear PTO and mid PTO are off at
once.
Mid
Mid + Rear
Rear
45
EG RPM MID PTO Speed
2875 2000 RPM
3000 2087 RPM
