ZED-F9T-Integration Manual
Figure 43: ZED-F9T tape dimensions (mm)
5.4 Reels
The ZED-F9T high accuracy timing receiver GNSS modules are deliverable in quantities of 250
pieces on a reel. The ZED-F9T high accuracy timing receiver receivers are shipped on Reel Type B,
as specified in the u-blox Package Information Guide. See the u-blox Package Information Guide [3].
5.5 Moisture sensitivity levels
The Moisture sensitivity level (MSL) for ZED-F9T high accuracy timing receivers is specified in the
table below.
Package MSL level
LGA 4
Table 24: MSL level
For MSL standard see IPC/JEDEC J-STD-020, which can be downloaded from
www.jedec.org.
For more information regarding moisture sensitivity levels, labeling, storage and drying, see
the u-blox Package Information Guide [3].
UBX-19005590 - R01
5 Product handling Page 76 of 80
Advance Information
