3. Place the two
hook-hinges (locat-
ed on the rear
bottom side of the
grille) on the front
lip of the unit
base. Swing the
grille up into posi-
tion, aligning the
grille and cabinet
screw holes (see
Figure 13).
4. Insert the screw,
being careful not
to over tighten.
14
User’s Manual
UL109
UL207
Figure 13
Figure 15
REVERSING THE DOOR
Depending upon the location of the unit, it may be desirable to change
the side on which the door is mounted.
To reverse the door mounting, perform the following:
UL116
REMOVE SCREW
Figure 14
1. Remove grille (1 screw) (see
Figure 14).
2. Remove top hinge from cabi-
net (3 screws) (see Figure
15). Hold door to keep it
from falling.
