Custom Door Panel Dimensions
Model A B
CLR 60 28-5/32" 13-15/16"
CLR 60SS 29-13/32" 13-15/16"
SS - Stainless steel units
Install the insert as follows:
Insert edges may be SHARP!
Use care when installing.
1. Remove top hinge screw pin
(large Phillips head, see
Figure 23). Hold door to
keep it from falling.
2. Remove door, being careful
not to scratch top of door on
hinge.
3. Remove two small screws
holding door handle. Slightly
separate door handle from
door (see Figure 24).
4. Pull door gasket out of
groove (top edge of door
only). Start in the middle and
pull outwards, moving
towards the edge (see Figure
25). This may take some
force.
5. Pull handle up and off.
6. Slide custom door panel
insert into 1/4 inch channel
in door front.
To Next Page
