User’s Manual
GLASS SHELF INSTALLATION
(for models with Glass Shelves)
1. Carefully remove the glass shelves from the packaging.
Figure 15
2. Slide the shelves onto lower two sets of ribs, making sure the sil-
ver edge strip is toward the front of the unit and the decorative
graphics are on the underside of the shelves. Make sure the
shelves are inserted fully into the unit (Figure 15). The white edge
strip toward the rear prevents cans and bottles from freezing
against the cold evaporator.
NOTE
Be sure to place shelves with the silver edge to the front
and decorative graphics on the underside. 75 BEV does not
have a silver edge strip.
75 BEV
UL108a
