REVERSING A STAINLESS STEEL DOOR
Stainless Steel models are field
reversible for left or right hand
opening. The door opening is easily
reversed by moving the hinge hard-
ware to the opposite side (Figure 33)
as follows:
1. Remove the bottom hinge
(two screws) from door.
2. Remove top hinge (two screws)
from door.
3. Remove door.
4. Remove top hinge (four screws)
from cabinet. Invert and install on
bottom, opposite side of cabinet.
5. Remove bottom hinge (four
screws) from cabinet. Invert and
install on top, opposite side of
cabinet.
6. Attach top hinge to door.
7. Attach bottom hinge to door.
8. Align as required to assure proper door seal.
UL318C
31
Figure 33
