CUSTOM DOOR PANEL INSERT
NOTE
The SP18 and 75 BEV models are not designed to accept
custom door panels.
A custom door panel can be installed on your U-Line unit to harmonize
with or accent the surrounding decor.
The door will accept a flat or raised panel. The maximum panel thick-
ness where inserted into the door reveal (channel) is 1/4” thick. For
raised panels, the depth of the reveal is 1/4” on the sides and bottom,
and 1/2” on the top. The size of the door panel insert is shown below:
The door panel insert must not weigh more than 20 lbs.
Custom Door Panel Dimensions
Model A B
BI-95 13–15/32” 12–15/16”
BI-98 15–15/16” 13–15/16”
75 Series 28–5/32” 22–15/16”
75 SS 29–13/32” 22–15/16”
29 Series 21–13/32” 19–13/16”
15 Series 28–5/32” 13–15/16”
15 SS 29–13/32” 13–15/16”
SS - Stainless steel units
B
A
