21
Figure 18
4. Remove two small screws
holding door handle. Slightly
separate door handle from
door (Figure 20).
5. Pull handle up and off.
UL131
Figure 19
Figure 20
UL132
Install the insert as follows:
Insert edges may be SHARP! Use care when installing.
1. Remove top hinge screw pin (large Phillips head, Figure 18). Hold
door to keep it from falling.
2. Remove door, being careful not to scratch top of door on hinge.
3. Pull door gasket out of groove (top edge of door only). Start in the
middle and pull outward, moving toward the edge (Figure 19). This
may take some force.
30035 User Manual Body.qxd 1/5/05 8:08 AM Page 21
