U-Line ICE-MAKER User Manual

45
Condenser Cleaning – Every Three Months
Disconnect electric power to the unit before cleaning the
condenser or the solenoid valve.
Figure 43
Keep the front grille free of dust and lint to allow air to flow to the con-
denser (Figure 43). Clean the condenser coil, located behind the front
grille. Use a brush or vacuum cleaner to remove dirt, lint and other
accumulations from the condenser coil.
To remove and replace the grille for access to the condenser fins
follow this procedure:
Figure 44
1. With a standard blade screwdriver (or 1/4” nutdriver), remove
the grille screw (Figure 44).
2. Remove the control knob by pulling it toward you.
3. Remove the grille.
UL116
REMOVE SCREW
UL005A
!
WARNING
30035 User Manual Body.qxd 1/5/05 8:08 AM Page 45

U-Line ICE-MAKER Specifications

General

Ice Shape	Crescent
Power Source	Electric
Voltage	115 V
Installation Type	Freestanding or Built-In
Finish	Stainless steel
Control Type	Digital
Water Supply	Direct Water Line Connection
Material	Stainless Steel
Warranty	1 year parts and labor
