Ubee DDW3612 User Manual

Ubee Interactive 3.7 Gateway
DDW3612 Subscriber User Guide • July, 2010 21
3.7.2 Gateway - Setup
The Setup option allows you to make basic configurations to the device.
1. Access the web interface. Refer to page 7, if needed.
2. Click the Gateway link from the top of the screen.
3. Click Setup from the left side of the screen. The Setup fields are explained
following this screen example.
Label Description
LAN IP Address Defines the local IP address, which will be the default
gateway address for all wired LAN hosts that connect to
the DDW3612 Wireless Cable Modem Gateway.
LAN MAC Address Displays the LAN interface’s hardware address.
WAN IP Address Displays the current WAN public IP address that is
obtained from the service provider.
WAN MAC Address Displays the WAN interface’s hardware address.
Duration Displays the accumulated time since successfully acquiring
a WAN public IP address.
Expires Displays the remaining time before the expiration of the
WAN IP address, if applicable.
Release WAN Lease Click to release the WAN public IP address.
Renew WAN Lease Click to renew the WAN IP address.
Refresh Click to refresh the status of this page.

Ubee DDW3612 Specifications

General

Brand	Ubee
Model	DDW3612
Category	Modem
Language	English
