3.7 Gateway Ubee Interactive
36 DDW3612 Subscriber User Guide • July, 2010
3.7.14 Gateway - Pass Through
The Pass Through option allows you to configure a pass through table. Devices in
the pass through table are treated as bridge devices, storing and forwarding data
between LAN interconnections.
1. Access the web interface. Refer to page 7, if needed.
2. Click the Gateway link from the top of the screen.
3. Click Pass Through from the left side of the screen. The Pass Through fields are
explained following this screen example.
Label Description
Index Index number of the pass through rule.
MAC Address Input the host’s MAC address.
Clear Select the box to delete this rule.
Apply Click to save.
