Ubee Interactive Using the Advanced Option
Ubee EVW32C Advanced Wireless Voice Gateway Subscriber User Manual • March 2017 57
3. Click Apply. The forwarding rule is created and displayed in the table as shown
below. Additional field descriptions follow.
Label Description
Local IP
Defines the IP address of the local LAN device to which the forwarding rule applies. For
example, an Xbox or PC.
Local Start Port Defines the starting port number listened to by the server host located in your LAN.
Local End Port Defines the ending port number listened to by the server host located in your LAN.
External IP Designates another router’s IP address on the network through which to forward data.
External Start Port Defines the port number to start the range of ports to publish to the Internet.
External End Port
Defines the port number to end the range of ports published to Internet.
Note: Be very careful with ranges. Ports within a range are not usable by other applications
that may require them. It is common and safer to enter the same port number as the start
and end of the range.
Protocol Selects the protocol type. Options are UDP, TCP, or BOTH.
Description Specifies the forwarding rule name.
Enabled Disables (Off) or enables (On) the forwarding rule.
Cancel
Stops the forwarding rule creation process and returns you to the previous Forwarding
screen.
Apply Saves changes.
Port Map Shows a list of common applications and their ports.
Forwarding Table – Lists existing forwarding rules.
Remove All Deletes all entries in the forwarding table.
