Examples of antennas
Table 36 lists some examples of possible internal on-board surface-mount antennas
Manufacturer
Part Number
Product Name
Description
Taoglas
PA.25.A
Anam
GSM / WCDMA SMD Antenna
824..960 MHz, 1710..2170 MHz
36.0 x 6.0 x 5.0 mm
Taoglas
PA.710.A
Warrior
GSM / WCDMA / LTE SMD Antenna
698..960 MHz, 1710..2170 MHz, 2300..2400 MHz, 2490..2690 MHz
40.0 x 6.0 x 5.0 mm
Taoglas
PA.711.A
Warrior II
GSM / WCDMA / LTE SMD Antenna
Pairs with the Taoglas PA.710.A Warrior for LTE MIMO applications
698..960 MHz, 1710..2170 MHz, 2300..2400 MHz, 2490..2690 MHz
40.0 x 6.0 x 5.0 mm
Taoglas
PCS.06.A
Havok
GSM / WCDMA / LTE SMD Antenna
698..960 MHz, 1710..2170 MHz, 2500..2690 MHz
42.0 x 10.0 x 3.0 mm
Antenova
A10340
Calvus
GSM / WCDMA SMD Antenna
824..960 MHz, 1710..2170 MHz
28.0 x 8.0 x 3.2 mm
Ethertronics
P522304
Prestta
GSM / WCDMA SMD Antenna
824..960 MHz, 1710..2170 MHz
35.0 x 9.0 x 3.2 mm
2J
2JE04
GSM / WCDMA SMD Antenna
824..960 MHz, 1710..2170 MHz
24.0 x 5.5 x 4.4 mm
Yaego
ANT3505B000TWPENA
GSM / WCDMA SMD Antenna
824..960 MHz, 1710..2170 MHz
35.0 x 5.0 x 6.0 mm
Table 36: Examples of internal surface-mount antennas
Table 37 lists some examples of possible internal off-board PCB-type antennas with cable and connector.
Manufacturer
Part Number
Product Name
Description
Taoglas
FXP14.A.07.0100A
GSM / WCDMA PCB Antenna with cable and U.FL connector
824..960 MHz, 1710..2170 MHz
70.4 x 20.4 mm
Taoglas
FXP14R.A.07.0100A
GSM / WCDMA PCB Antenna with cable and U.FL connector
Integrated 10k shunt diagnostic resistor
824..960 MHz, 1710..2170 MHz
80.0 x 20.8 mm
Taoglas
PC29.09.0100A
TheStripe
GSM / WCDMA PCB Antenna with cable and MMCX(M)RA connector
824..960 MHz, 1710..2170 MHz
80.4 x 29.4 mm
Taoglas
FXUB63.07.0150C
GSM / WCDMA / LTE PCB Antenna with cable and U.FL connector
698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2400..2690 MHz
96.0 x 21.0 mm
Ethertronics
P522310
Prestta
GSM / WCDMA PCB Antenna with cable and U.FL connector
824..960 MHz, 1710..2170 MHz
41.0 x 15.0 mm
EAD
FSQS35241-UF-10
SQ7
GSM / WCDMA / LTE PCB Antenna with cable and U.FL connector
690..960 MHz, 1710..2170 MHz, 2500..2700 MHz
110.0 x 21.0 mm
Yaego
ANTX100P001BWPEN3
GSM / WCDMA PCB Antenna with cable and I-PEX connector
824..960 MHz, 1710..2170 MHz
50.0 x 20.0 mm
Table 37: Examples of internal antennas with cable and connector
