Ublox SARA-G340 ATEX User Manual

SARA-G3 and SARA-U2 series - System Integration Manual
UBX-13000995 - R26 Approvals
Page 190 of 217
Table 66 lists the maximum input and equivalent parameters that must be considered in sub-division IIB and IIA
for SARA-G340 ATEX, SARA-G350 ATEX, SARA-U201 ATEX and SARA-U270 ATEX (two different configurations
are allowed for SARA-U201 ATEX).
Parameter
SARA-G340 ATEX
SARA-G350 ATEX
SARA-U201 ATEX
SARA-U270 ATEX
Ui
4.2 V
4.2 V
3.8 V
4.2 V
Ii
2.5 A (burst)
1.6 A (burst)
2.5 A (burst)
2.5 A (burst)
Ci
103 µF
169 µF
169 µF
132 µF
Li
4.1 µH
9.4 µH
9.4 µH
9.8 µH
Table 66: Maximum input and equivalent parameters for sub-division IIB and IIA

Ublox SARA-G340 ATEX Specifications

General

Brand	Ublox
Model	SARA-G340 ATEX
Category	Control Unit
Language	English
