SARA-G450 - System integration manual
UBX-18046432 - R08 Appendix Page 135 of 143
C1-Public
SDIO serial data [3]
36
Configurable as SPI_CS
(diagnostic only)
SDIO serial data [1]
36
Configurable as SPI_MISO
(diagnostic only)
Module supply input
Normal op. range:
3.20 ÷ 4.20 V
Extended op. range:
3.00 ÷ 4.30 V
No turn-on by VCC apply
Module supply input
Normal op. range:
3.20 ÷ 4.50 V
Extended op. range:
3.00 ÷ 4.50 V
No turn-on by VCC apply
Module supply input
Normal op. range:
3.30 ÷ 4.40 V
Extended op. range:
3.00 ÷ 4.50 V
SARA-R510S:
No turn-on by VCC apply
SARA-R500S/R510M8S:
Turn-on by VCC apply
Module supply input
Normal op. range:
3.10 ÷ 4.00 V
Extended op. range:
2.75 ÷ 4.20 V
Turn-on by VCC apply
Module supply input
Normal op. range:
3.20 ÷ 4.20 V
Extended op. range:
2.60 ÷ 4.20 V
No turn-on by VCC apply
Module supply input
Normal op. range:
3.35 ÷ 4.50 V
Extended op. range:
3.00 ÷ 4.50 V
Turn-on by VCC apply
Module supply input
Normal op. range:
3.40 ÷ 4.20 V
Extended op. range:
3.10 ÷ 4.50 V
No turn-on by VCC apply
Module supply input
Normal op. range:
3.30 ÷ 4.40 V
Extended op. range:
3.10 ÷ 4.50 V
Turn-on by VCC apply
Bluetooth RF I/O
36
It can be grounded
Table 49: SARA-N2, SARA-N3, SARA-R4, SARA-R5, SARA-G3, SARA-G4 and SARA-U2 series modules pin assignment and description, with remarks for migration
☞ For further details regarding characteristics, capabilities, usage or settings applicable for each interface of the SARA-N2, SARA-N3, SARA-R4, SARA-R5, SARA-G3, SARA-G4 and SARA-U2
cellular modules, see the related data sheet [1], [2], [3], [4], [5], [6], [7], the related system integration manual [8], [9], [10], [11], and the nested design application note [17].
Not supported by “00”, “01”, “x2” and “x3” product versions
Not supported by “00” product version
Not supported by “02” product version
