SARA-G450 - System integration manual
UBX-18046432 - R08 Design-in Page 81 of 143
C1-Public
Table 25 lists some examples of internal off-board PCB-type antennas with cable and connector.
Manufacturer
Part number
Product name
Description
Taoglas
FXP14.A.07.0100A
GSM / WCDMA PCB antenna with cable and U.FL connector
824..960 MHz, 1710..2170 MHz
70.4 x 20.4 mm
Taoglas
FXP14R.A.07.0100A
GSM / WCDMA PCB antenna with cable and U.FL connector
Integrated 10k shunt diagnostic resistor
824..960 MHz, 1710..2170 MHz
80.0 x 20.8 mm
Taoglas
PC29.09.0100A
TheStripe
GSM / WCDMA PCB antenna with cable and MMCX(M)RA
824..960 MHz, 1710..2170 MHz
80.4 x 29.4 mm
Taoglas
FXUB63.07.0150C
GSM / WCDMA / LTE PCB antenna with cable and U.FL connector
698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2400..2690 MHz
96.0 x 21.0 mm
Ethertronics
P522310
Prestta
GSM / WCDMA PCB antenna with cable and U.FL connector
824..960 MHz, 1710..2170 MHz
41.0 x 15.0 mm
EAD
FSQS35241-UF-10
SQ7
GSM / WCDMA / LTE PCB antenna with cable and U.FL connector
690..960 MHz, 1710..2170 MHz, 2500..2700 MHz
110.0 x 21.0 mm
Yaego
ANTX100P001BWPEN3
GSM / WCDMA PCB antenna with cable and I-PEX connector
824..960 MHz, 1710..2170 MHz
50.0 x 20.0 mm
Table 25: Examples of internal antennas with cable and connector
Table 26 lists some examples of possible external antennas.
Manufacturer
Part number
Product name
Description
Taoglas
GSA.8827.A.101111
Phoenix
GSM / WCDMA / LTE low-profile adhesive-mount antenna with cable
and SMA(M) connector
698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2490..2690 MHz
105 x 30 x 7.7 mm
Taoglas
GSA.8821.A.301721
I-Bar
GSM / WCDMA low-profile adhesive-mount antenna with cable and
Fakra (code-D) connector
824..960 MHz, 1710..2170 MHz
106.7 x 14.7 x 5.8 mm
Taoglas
TG.30.8112
GSM / WCDMA / LTE swivel dipole antenna with SMA(M) connector
698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2400..2700 MHz
148.6 x 49 x 10 mm
Taoglas
OMB.8912.03F21
GSM / WCDMA pole-mount antenna with N-type (F) connector
824..960 MHz, 1710..2170 MHz
527 x Ø 26 mm
Taoglas
FW.92.RNT.M
GSM / WCDMA whip monopole antenna with RP-N-type(M) connector
824..960 MHz, 1710..2170 MHz
274 x Ø 20 mm
Nearson
T6150AM
GSM / WCDMA swivel monopole antenna with SMA(M) connector
824..960 MHz, 1710..2170 MHz
179.3 x 22 x 6.5 mm
Laird Tech.
MAF94300
HEPTA-SM
GSM / WCDMA swivel monopole antenna with SMA(M) connector
824..960 MHz, 1575.42 MHz,1710..2170 MHz, 2400..2500 MHz
161 x 9.3 mm
Laird Tech.
TRA806/171033P
GSM / WCDMA screw-mount antenna with N-type(F) connector
824..960 MHz, 1710..2170 MHz
69.8 x Ø 38.1 mm
