Ultimaker 3 Original Manual

30
5.5 Removing the print
Once your 3D print is finished it must be removed from the build plate. There are several methods to use, depending on
how the print is adhered to the build plate.
Wait for cool down
If you printed directly on the glass plate without using an adhesive and if the build plate was not leveled too tight, the print
may easily be removed once it is cool. Simply allow the build plate and the print to cool down after printing. The material
will contract as it cools and you can easily remove the print from the build plate.
Use a spatula
If your print doesn’t remove from the build plate after cooling, you can use a spatula to remove the print. Place the spatula
under the print and apply a small amount of force to remove the print.
Take the glass plate out of the printer to avoid damage on the build plate clamps.
Use water
If neither of these methods works, remove your print using water. Remove the glass plate and print from the Ultimaker 3.
Be careful not to burn your fingers if the glass plate is still warm. Run cool tap water on the back side of the plate to cool
quickly. The print material will contract more than with normal cool down. Once cool, the print can be popped off.
If glue was used on the glass plate, run lukewarm water over the print side of the plate to dissolve the glue. Once the glue
is dissolved, it is easier to remove the print. If PVA was used, place the glass plate and print in water to dissolve the PVA.
This makes print removal easier.

Ultimaker 3 Specifications

General

Manual	Yes
Bundled software	Cura 2
Included filament roll weight	0.35 kg
Number of filament rolls included	2
Storage temperature (T-T)	0 - 32 °C
Operating temperature (T-T)	15 - 32 °C
Input current	4 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	221 W
Package depth	380 mm
Package width	390 mm
Package height	560 mm
Package weight	15500 g
Card reader integrated	-
Accuracy	0.0125 mm
Nozzle width	0.4 mm
Print technology	Fused Filament Fabrication (FFF)
Printing material	Chlorinated Polyethylene (CPE), ABS, Nylon, Polylactic acid (PLA), PVA
Layer thickness (max)	0.2 mm
Layer thickness (min)	0.02 mm
Layer thickness supported	0.02, 0.2 mm
Maximum build size (WxDxH)	- mm
Filament thickness supported	2.85 mm
Maximum vertical build speed	300 mm/sec
Control type	Buttons, Rotary
Product color	White
Model file formats supported	obj, stl
Maximum extruder tip temperature	280 °C
Maximum print platform temperature	100 °C

Weight and Dimensions

Width	342 mm
Height	389 mm
