Ultimaker S5 Quick Start Guide

EN
Safety messages
This quick start guide contains warnings and safety notices.
Provides additional information that is helpful to do a task or to
avoid problems.
Warns of a situation that may cause material damage or injuries
if one does not follow the safety instructions.
Ultimaker S5 and Ultimaker S5 Pro Bundle
This quick start guide describes different installation procedures. To install
the standalone Ultimaker S5, follow the instructions on the next page.
If you have the complete Ultimaker S5 Pro Bundle, skip these steps and go
straight to Install the Ultimaker S5 Pro Bundle. The sections Set up for rst
use and Start a print apply to both congurations.
Ultimaker
Stationsplein 32
3511 ED Utrecht
The Netherlands
+31 883 83 40 00
User manual
You can nd the full Ultimaker S5 and
Ultimaker S5 Pro Bundle user manuals,
available in English and many other
languages, on our website:
ultimaker.com/manuals
Support
For more information on technical
support visit ultimaker.com/support
or contact your local reseller

Ultimaker S5 Specifications

General

Build Volume	330 x 240 x 300 mm
Layer Resolution	20 - 600 microns
Filament Diameter	2.85 mm
Max Nozzle Temperature	280 °C
Max Build Plate Temperature	140 °C
Print Technology	Fused Filament Fabrication (FFF)
Number of Print Heads	2
Build Plate	Heated glass build plate
Operating Sound	50 dBA
Print Speed	Up to 24 mm³/s
Display	4.7-inch color touchscreen
Operating Temperature	15 - 32 °C
Nozzle Diameter	0.25, 0.4, 0.6, 0.8 mm
Connectivity	Ethernet, Wi-Fi, USB
Supported Materials	PLA, ABS, Nylon, CPE, PVA, TPU 95A, PC, PP
Dimensions	495 x 585 x 780 mm
Feeder Type	Dual-geared
Print Head Movement Speed	300 mm/s
Build Plate Heating Time	Less than 4 minutes
Power Consumption	350 W
Travel Speed	300 mm/s
Operating Humidity	20 - 80% (non-condensing)
