Ultimaker S5 Quick Start Guide

Ultimaker
S5 (Pro Bundle)
This quick start guide will help you set
up your Ultimaker S5 and Ultimaker S5
Pro Bundle for rst use.
The Ultimaker S5 is built to maximize
uptime with great print results and
a large build volume. By enhancing
this award-winning 3D printer with
What’s in the box?
Accessories
• Glass plate
• Spool holder with material guide*
• Power cable
• Ethernet cable
• USB stick
• Print core AA 0.4 (2x)
One of the AA print cores is already
insertedinto print head slot 1
Please retain all packaging
for warranty purposes.
Tools
• Hex screwdriver 2 mm
* Not required for the complete
Ultimaker S5 Pro Bundle
• Print core BB 0.4 (1x)
• XY calibration sheet
• Calibration card
• Nozzle cover (3x)
Consumables
• Tough PLA Black 750 g
•
PVA 750 g
• Glue stick
• Oil
• Grease
the Material Station and Air Manager,
the Ultimaker S5 Pro Bundle boosts
productivity, exibility, and condence
to
unlock demanding applications with
an extended range of materials.

Ultimaker S5 Specifications

General

Build Volume	330 x 240 x 300 mm
Layer Resolution	20 - 600 microns
Filament Diameter	2.85 mm
Max Nozzle Temperature	280 °C
Max Build Plate Temperature	140 °C
Print Technology	Fused Filament Fabrication (FFF)
Number of Print Heads	2
Build Plate	Heated glass build plate
Operating Sound	50 dBA
Print Speed	Up to 24 mm³/s
Display	4.7-inch color touchscreen
Operating Temperature	15 - 32 °C
Nozzle Diameter	0.25, 0.4, 0.6, 0.8 mm
Connectivity	Ethernet, Wi-Fi, USB
Supported Materials	PLA, ABS, Nylon, CPE, PVA, TPU 95A, PC, PP
Dimensions	495 x 585 x 780 mm
Feeder Type	Dual-geared
Print Head Movement Speed	300 mm/s
Build Plate Heating Time	Less than 4 minutes
Power Consumption	350 W
Travel Speed	300 mm/s
Operating Humidity	20 - 80% (non-condensing)
