UNI-T UDP6900 Series Service Manual

Service Manual UDP6900 Series Digital Control Power Supply
Instruments.uni-trend.com 12 / 29
Accessory List
No.
Article
Description
1
Handle
Pull the handle to both sides by slightly force, rotate vertically along the
direction of the host panel to the top of the machine, and then pull away
on both sides
2
Case frame
Outer Frame
Accessory List
No.
Article
Description
1
KM3X6 quincunx
screws
Use T10 quincunx screwdriver to remove 1 screws
2
Case frame
3
Outer frame
Pull to the back of the case
Rear Panel
