No. MeaningSymbol
Display Symbols (1) (see figure 2)
(figure 2)
1
The Meter is in the auto range mode in
which the Meter automatically selects the
range with the best resolution.
2
The battery is low.
Warning: To avoid false readings,
which could lead to possible electric
shock or personal injury, replace the
battery as soon as the battery indicator
appears.
3
Indicates negative reading.
4
Test of diode.
5
The continuity buzzer is on.
6
The relative value mode is on, which
display the present value minus the stored
value.
%
7
The relative percentage value mode is
on. It displays the percentage value of
the relative value and stored value.
DATA
HOLD
8
Data hold is active.
DC AC Indicator for DC/AC voltage or current.
The displayed value is the mean value.
9
Display the present chosen range.8000mV
10
Percent, used for duty cycle
measurements.
%
11
Model UT70C: OPERATING MANUAL
