Warning
To avoid false readings, which could lead to possible
electric shock or personal injury, replace the battery
as soon as the battery indicator "
" appears.
To replace the battery:
1. Turn the Meter to OFF position and remove all
connections from the terminals.
2. Take out the Meter from the holster.
3. Remove the 3 rubber feet and then 3 screws from
the case bottom, and separate the case top from
the case bottom.
4. Remove the battery from the battery connector.
5. Replace the battery with a new 9V battery
(NEDA1604, 6F22 or 006P).
6. Rejoin the case bottom and case top, and reinstall
the 3 screws and 3 rubber feet.
(figure 15)
Maintenance (3)
C. Replacing the Battery (see figure 15)
The Meter
Holster
Model UT70C: OPERATING MANUAL
43
