MAX MIN recording mode applies to all measurement
functions except at conductance measurement function.
MAX MIN recording mode captures and stores the
maximum and minimum input value detected, and
calculates a running average of all readings taken.
In the MAX MIN mode, when the Meter detects an input
that is below the recorded minimum or above the recorded
maximum, the Meter beeps and records the new minimum
(MIN) or maximum (MAX) value.
In the MAX MIN mode, you can also display a running
average of all readings taken since the MAX MIN mode
was activated. Displaying the average reading allows
you to "smooth" a rapidly changing input by displaying
a stable reading on the digital display.
The MAX MIN mode has a pre-set response time of
100ms. A shorter response time captures shorter events,
but with decreased accuracy. If you want 1 second
response time, that can be selected after power on the
Meter.
To use the MAX MIN mode as follows:
(figure 13)
MAX MIN Recording Mode (1) (see figure 13)
Select MAX,
MIN, AVG or
Present value
blackred
Model UT70C: OPERATING MANUAL
28
