UTD2000 Series User Manual
16
signal.
(4) Press DEFAULT to display “Factory Setting” window, press SELECT to execute
factory setting, press MENU to stop factory setting and close the window.
(5) Press HELP to display “HELP” window, press HELP again to close the window.
Chapter II Vertical System
UTD2000 series DSO provides two analog input channels, each channel has an
independent vertical menu. Each channel for UTD2000 series DSO can be set
independently through the vertical system menu. After pressing CH1 or CH2 function key,
the system shall display function menu of CH1 or CH2 channel. See Table 2-1 below for
description.
Table 2-1 Channel Menu (Page 1)
Block the DC component of input signal.
Pass through DC and AC components of input signal.
Display grounding level (Input signal is not disconnected).
Limit bandwidth to 20MHz to reduce high-frequency component of detected
signal.
Turn off bandwidth limit, the DSO runs through full bandwidth.
Set vertical scale of current channel based on 1-2-5 scale.
Fine Volts/Div is within the range of coarse Volts/Div setting, set the vertical scale
of current channel based on 1% step of current Volts/Div scale.
0.01×
0.02×
...
100×
1000×
Based on probe attenuation coefficient, you select a value to ensure the
consistency of vertical scale reading and actual displayed waveform so that you
don’t need to calculate by multiplying the probe attenuation coefficient.
Activate reverse function of waveform. Waveform will be displayed reversely.
Waveform is displayed normally.
Table 2-2 Channel Menu (Page 2)
Display the unit of current channel range
To Next Page
