Chapter XIV Technical Information
Except for those specifications marked with “Typical”, all specifications have
warranties.
Unless otherwise specified, all technical specifications are applicable to the probes
with attenuation switch set as 10× as well as UTD2000 series DSO. DSO must first meet
the following two conditions to meet those specification standards:
 The instrument must continuously operate for over half an hour within the operating
temperature.
 If the change scope of operating temperature is or exceeds 5°C , please perform the
“Self-Adjustment” function in the UTILITY system function.
Acquire System Specification
Model
UTD2072CL
UTD2152CL
UTD2102CEX+
UTD2202CEX+
Real-time
500MS/s
500MS/s
1GS/s
1GS/s
Equivalence
50GS/s
50GS/s
50GS/s
50GS/s
Average
When the sampling times of all channels are N, N can be chosen among 2, 4, 8, 16, 32, 64,
128 and 256
Input Channel Specifications
Input Coupling
DC, AC and GND
Input impedance
(1MΩ± 2%)//(18pF± 3 pF)
Probe attenuation
coefficient
0.01×/0.02×/0.05×/0.1×/0.2×/0.5×/1×/2×/5×/10×/20×/50×/100×/200×/500×/1000×
Maximum input
voltage
300Vrms, the transient over voltage is 1000 Vpk.
Horizontal System Specification
Time-base scale
2ns/div-50s/div
Waveform interpolation
Sin(x)/x
Time-base accuracy
≤± （50 + 2 × service life）ppm
Record length
2×512k sampling point
Storage depth
Single channel: 64k；Double channel: 32k
Sampling rate and delay
time accuracy
±50ppm (any time interval ≥1ms )
Measurement accuracy of
time interval (△T) (full
bandwidth)
Single time: ± (1 sampling time interval+50ppm×reading+0.6ns)
>16 average values: ± (sampling time interval+50ppm×reading+0.4ns)
