UTD2000 Series User Manual
58
Analog-to-digital
converter (A/D)
Deflection factor range
(V/div)
1mV/div~20 V/div(at 1-2-5 increment)
Selectable bandwidth
limitation (Typical)
Low frequency response
(AC Coupling,-3dB)
(sampling or average
sampling mode)
When vertical position is 0 and N≥16:
± (4%×reading+0.1div+1mV) and selects 1mV ~2mV/div;
± (3%×reading+0.1div+1mV) and selects 10mV~20V/div;
When vertical position is not 0 and N≥16:
±(3%×(reading + vertical position reading) + (1%×vertical position reading)]+0.2div)
The setting from 5mV/div to 200mV/div plus 2mV;
the setting value from 200mV/div to 20V/div plus 50mV
Measurement accuracy
of voltage difference
(△V) (average sampling
mode)
Under the same setting and environment conditions and after averaging the captured
waveforms with a quantity of ≥16, the voltage difference (ΔV) between any two points
on the waveform: ± (3%×reading+0.05div)
Trigger System Specifications
Interior:From the screen center ±10div
Trigger level accuracy
(Typical) applicable for the
signal with rising and falling
time ≥20ns
Interior:±(0.3div×V/div) (within±4 div from the screen center)
EXT:±(6% setting value+40mV)
Normal mode/scan mode, pre-trigger/delay trigger, the pre-trigger depth is
