adjustable.
Hold-off range
80ns~1.5s
Set the level to 50%
(Typical)
Operate under the condition of input signal frequency of ≥50Hz
Trigger mode
AUTO, normal, single
High-frequency holdoff
Hold off signals over 80kHz
Low-frequency holdoff
Hold off signals below 80kHz
Edge trigger
Edge
Rise, fall, rise&fall
Pulse width trigger
Trigger mode
>, <, =
Polarity
positive pulse width, negative pulse width
Pulse width range
20ns~10s
Slope trigger
Slope condition
Positive slope (>, <, within the scope)
Negative slope (>, <, within the scope)
Time setting
20ns~10s
Video trigger
Trigger sensitivity (Typical)
2div Vpp
Signal model and line/field
frequency (video trigger
type)
Support standard NTSC and PAL, and the line number scope is respectively 1-
525 (NTSC) and 1-625 (PAL)
Alternating trigger
Alter
Edge, Pulse, Slope
Measurements
Cursor
Manual mode
Voltage difference between cursors (△V),
Time difference between cursors (△T),
Reciprocal of △T (Hz) (1/△T))
Track mode
Voltage value and time value of point of waveform.
Auto
measurement
mode
Cursor display is allowed on auto measurement mode.
Automatic
measurement
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vmid, Average, Vrms, Overshoot, Preshoot,
Frequency, Period, RiseTime, FallTime, +Width, -Width, +Duty, -Duty, Delay, FRFR, FRFF,
FFFR, FFFF, FRLF, FRLR, FFLR, FFLF
Measurement
quantity
Display 5 types of measurement at the same time.
