UTG1000A Series 29
4.1.2 Frequency Modulation (FM)
In frequency modulation, modulated waveform is usually composed of carrier wave and modulation shape. Carrier
wave frequency will change as the amplitude of modulation shape changes.
Press Menu→Modulation→Type→ Frequency Modulation in turn to start the FM function. The device will output
modulated waveform with modulation waveform and carrier wave set currently.
Carrier Wave Waveform Selection
FM carrier waveform can be: Sine wave, square wave, ramp wave, pulse wave, arbitrary wave (except DC) and noise
(the default is sine wave). After selecting FM modulation, press Carrier Wave Parameter softkey to enter carrier
waveform selection interface.
