UTG1000A Series 49
4.1.5 Frequency Shift Keying (FSK)
In frequency shift keying, rate of carrier wave frequency and hopping frequency can be changed.
FSK Modulation Selection
PressMenu→Modulation→Type→Frequency Shift Keying in turn to start the FSK function. The device will output
modulated waveform with current setting.
Carrier Wave Waveform Selection
Press Carrier Wave Parametersoftkey to enter carrier waveform selection interface. FSK carrier waveform can be:
sine wave, square wave, ramp wave or arbitrary wave (except DC), and the default is sine wave.
Carrier Wave Frequency Setting
Settable carrier wave frequency range is different of different carrier waveform. Default frequency of all carrier
wave is 1kHz. The frequency setting range of each carrier wave can be seen in the following table:
To Next Page
