UNI-T UTG1000 Series User Manual

UTG1000A Series 43
4.1.4 Amplitude Shift Keying (ASK)
ASK represents digital signal “0” and “1” by changing amplitude of carrier wave signal. Carrier wave signal with
different amplitude will be output on the basis of different logic of modulation signal.
ASK Modulation Selection
Press Menu→Modulation→Type→Amplitude Shift Keying in turn to start the ASK function, the device will output
modulated waveform with ASK rate and carrier wave set currently.
Carrier Wave Waveform Selection
ASK carrier waveform can be: Sine wave, square, ramp wave or arbitrary wave (except DC), and the default is sine
wave. Press Carrier Wave Parameter softkey to enter carrier waveform selection interface.
