UNI-T UTG1000 Series User Manual

UTG1000A Series 81
Appendix B Technical Specifications
Type UTG1020A UTG1010A UTG1005A
Channel Single Channel
Max. Frequency 20MHz 10MHz 5MHz
Sample Rate 125MSa/s
Waveform Sine Wave, Square Wave, Triangle Wave, Pulse Wave, Ramp Wave,
Noise, DC, Arbitrary Waveform
Working Mode Output Stobe, Duration, Modulation, Scanning
Modulation Type
AM、FM、PM、ASK、FSK、PSK、PWM
Features of Waveform
Sine Wave
Frequency Range 1μHz~20M
Hz
1μHz~10M
Hz
1μHz~5MHz
Resolution
1μHz
Accuracy
±50ppm in 90 days，±100ppm in one year （18°C~28°C）
Harmonic Distortion
（Typical Value）
Test Condition：utput power 0dBm
-55dBc
-50dBc
-40dBc
Total Harmonic Distortion
（Typical Value）
DC~20kHz，1Vpp＜0.2%
Square Wave
Frequency Range 1μHz~5MHz
Resolution 1μHz
Lead/Tail Time
＜24ns（typical value，1kHz，1Vpp）
Overshoot（Typical Value） ＜2%
Duty Cycle 0.01%~99.99%
Min.Pulse ≥80ns
Jittering（Typical Value）
1ns+ 100ppm of period
Ramp Wave
