UNI-T UTG1000 Series User Manual

82 UTG1000A Series
Frequency Range 1μHz~400kHz
Resolution 1μHz
Nonlinear Degree
1%±2 mV（typical value，1kHz，1Vpp，symmetry 50%）
Symmetry 0.0% to 100.0%
Min. Edge Time ≥400ns
Pulse Wave
Frequency Range 1μHz~5MHz
Resolution 1μHz
Pulse Eidth ≥80ns
Lead/Tail Time
＜24ns （typical value，1kHz，1Vpp）
Overshoot（Typical Value） ＜2%
Jittering（Typical Value）
1ns+ 100ppm of period
DC Offset
Range（Peak Value AC+DC） ±5V（50Ω）
±10V （High Resistance）
Offset Precision
±（|1% of offset setting|+0.5% of ampltide +2mV）
Features of Arbitrary Waveform
Frequency Range 1μHz~3MHz 1μHz~2MHz 1μHz~1MHz
Resolution 1μHz
Waveform Length 2048 points
Vertical Resolution
14bits（including symbols）
Sample Rate 125MSa/s
Non-volatile Memory 16 types of waveform
Output Features
Amplitude Range
1mVpp~10Vpp（50Ω，≤10MHz）
1mVpp~5Vpp（50Ω，≤20MHz）
1mVpp~10Vpp （50Ω）
2mVpp~20Vpp（high resistance, ≤
10MHz）
2mVpp~10Vpp（high resistance, ≤
20MHz）
2mVpp~20Vpp（high resistance）
Accuracy 1% of amplitude setting value ±2 mV
