84 UTG1000A Series
FSK Modulation
Carrier Wave Sine Wave, Square Wave, Ramp Wave, Arbitrary Wave
Source Internal/External
Modulation Shape Square Wave of 50% duty cycle
Modulation Frequency 2mHz~100kHz
PSK Modulation
Carrier Wave Sine Wave, Square Wave, Ramp Wave, Arbitrary Wave
Source Internal/External
Modulation Shape Square wave of 50% duty cycle
Modulation Frequency 2mHz~100kHz
PWM Modulation
Carrier Wave Pulse Wave
Source Internal/External
Modulation Shape Sine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency 2mHz~50kHz
Width Deviation
0%~49.99% of pulse width
Sweep
Carrier Wave Sine Wave, Square Wave, Ramp Wave
Type Linearity, Logarithm
Sweep Time 1ms~500s±0.1%
Trigger Source Manual, Internal, External
Synchronous Signal
Output Level TTL compatible
Output Frequency 1μHz~10M
Hz
1μHz~10M
Hz
1μHz~5MHz
Output Resistance
50Ω，typical value
Coupled Mode
Direct Current
Front Panel Connector
Modulation Input
±5Vpk during the whole measurement
20kΩ of input resistance
Trigger Output TTL compatible
