UNI-T UTG1000X Series User Manual

User’s Manual UTG1000X Series
Instruments.uni-trend.com 30 / 74
parameter to kHz;
Press Amp soft key to set the amplitude, use numerical keyboard to input 100 and then select the unit of
parameter to mV.
4) Set Frequency Deviation
After the parameter setting of the carrier wave is completed, press ModeShapeFM to enter FM mode
setting,
Press FreqDev soft key and use numerical keyboard to input 5 and then select the unit of parameter to
kHz.
5) Enabling Channel Output
Press CH1 key, if the indicator light is illumined which means the channel output is enabled.

UNI-T UTG1000X Series Specifications

General

Brand	UNI-T
Model	UTG1000X Series
Category	Portable Generator
Language	English
