3) Set Carrier Wave Signal
Press Wave key to enter the carrier wave interface and select sine wave to be the carrier wave (the default
is sine wave).
Press Freq soft key to set the frequency, use numerical keyboard to input 2 and then select the unit of
parameter to kHz;
Press Amp soft key to set the amplitude, use numerical keyboard to input 1 and then select the unit of
parameter to Vpp.
4) Enabling Channel Output
Press CH1 key, if the indicator light is illumined which means the channel output is enabled.
