User’s Manual UTG1000X Series
Instruments.uni-trend.com 39 / 74
To view the shape of the ASK through an oscilloscope as shown in the following figure.
4.1.5 Frequency Shift Keying (FSK)
In FSK mode, it can set the switch rate between the frequency of carrier wave and hopping frequency for
the instrument.
Select FSK
Press ModeShape FSK to turn on FSK mode, the instrument will output the modulated waveform
according to the currently setting.
