47
►List of wirings
REFERENCE DESIGNATION CONNECTOR
NB
PINS
VOLTAGE
QUANTITY
SOLO DUO MT FRIGO
FR8019 BLUE CABLE CONN. COIL AND CONTACT High 1 2 2
FR8029 OPTICAL CELLS WITH CONNECTOR CN6 16 Low 1
FR8055 EV SV EV EXTENSION CABLE Low 1 1 1
TG8012 USB LINK CABLE CN2 4 Low 1 1 1
TG8013 RS 232 TFT SCREEN LEFT CN3 16 Low 1 1
TG8014 RS 232 TFT SCREEN RIGHT CN4 16 Low 1 1
TG8016 MOTOR TRAY ADAPTER CABLE CN22 2 Low 1 1 1
TG8017 STEAM BOILER & MAINS CABLE CN7 10 Low 1 1 1
TG8027 THERMOSTAT PROBES & LEVEL PROBES
CN17 10
Low 1 1 1CN26 4
CN27 4
TG8029 RIGHT CONTROL CABLE
CN14 4
Low 1 1CN38 8
CN39 4
TG8030 COFFEE GROUNDS DRAWER SAFETY CN20 4 Low 1 1 1
TG8034 BIN, BLENDER, POWDER FAN CN24 12 Low 1
TG8037
CABLE, TRAP & PIST. COD. SAFETY
MOTOR CTRL
CN8 4
Low 1 1 1
CN9 4
CN12 6
CN15 6
CN23 4
CN25 2
TG8038 Cable, STAT relay CONTROL. HOT MT CN30 6 Low 1
TG8039 STAT relay CTRL. HOT STEAM / COFFEE CN29 6 Low 1 1 1
TG8040 Cable, STAT relay CONTROL. HOT STEAM CN30 6 Low 1
TG8041 SV CTRL, REFRIGERATOR PUMP PART 1
CN32 6
Low 1CN36 6
CN50 12
TG8042 SV CTRL, REFRIGERATOR PUMP PART 2 Low 1
TG8043 CÂBLE CMD EVRE, EVSE ,EVSV,EVKG CN34 20 Low 1 1 1
TG8045 CÂBLE EV CAPPUCCINO LEFT CN35 6 Low 1 1
TG8049 CÂBLE CPU GND FRONT PANEL Earth 1 1 1
TG8050 CÂBLE GRINDER R,V,O,RES GR,RI,PUMP
CN41 12
High 1 1 1CN44 8
CN47 6
TG8057 CABLE, COFFEE BOILER High 1
TG8058 CABLE, COFFEE STEAM GROUP High 1 1 1
TG8059 CABLE, STATIC RELAY JUMPER High 3 1
TG8060 CABLE, MT BOILER High 1
TG8062 CABLE, SWITCH OUTPUT High 1 1 1
TG8100 CÂBLE INTER, DISPLAY T°C REG C- F High 1
TG8101 SUPPLY CABLE High 1
