65
►TFT screen replacement
Example with a grille of the Tango Solo ST
Tools:
-Phillips screwdriver
-Flat-blade screwdriver
Remove the glass cover of the cup heater
and unscrew the 2 screws at the front.
Unscrew the 2 screws underneath, while
holding the grille so that it does not fall.
Earth
USB cable
connecting cable
Remove the grille and disconnect the 3
connectors.
Fan connector
Unscrew the 8 screws and disconnect
the fan connector.
Remove the support plate from the grille.
Unscrew the 5 screws from the
underneath.
1 2
3 4
5 6
