Technical Features
ENGLISH
MODULEX EXT 348 EXT 440 EXT 550 EXT 660 EXT 770 EXT 900
Boiler category II
2H3P
II
2H3P
II
2H3P
II
2H3P
II
2H3P
Modulation ratio 1:15.8 1:19.6 1:24.5 1:29.4 1:34.3 1:39.2
Rated heat output on P.C.I. Qn kW 348 432 540 648 756 864
Minimum heat output on P.C.I. Qmin kW 22
E󰀨ective nominal output (Tr 60 / Tm 80 °C) Pn kW 341.7 424.3 530.4 636.5 742.6 849.0
Minimum e󰀨ective output (Tr 60 / Tm 80 °C) Pn min kW 20.6
E󰀨ective nominal output (Tr 30 / Tm 50 °C) Pcond kW 359.2 445.0 557.8 670.1 783.2 900.3
Minimum e󰀨ective output (Tr 30 / Tm 50 °C) Pcond min kW 23.9
Nominal output performance (Tr 60 / Tm 80°C) % 98.2
Minimum output performance (Tr 60 / Tm 80°C) % 93.5
Nominal output performance (Tr 30 / Tm 50°C) % 104
Minimum output performance (Tr 30 / Tm 50°C) % 109
Performance at 30% of the load (Tr 30°C) 106.8 107.3 107.5 108.3 107.8 107.6
Combustion e󰀩ciency at nominal load % 97.8
Combustion e󰀩ciency with reduced load % 98.5
Casing heat loss with burner on (Qmin) % 5.04
Casing heat loss with burner on (Qn) % 0.1
Net ue gas temperature tf-ta (min)(*) °C 31
Net ue gas temperature tf-ta (max)(*) °C 46.0 46.7 46.7 46.7 46.7 45.8
Maximum permitted temperature °C 100
Maximum operating temperature °C 85
Flue gas mass ow rate (min) kg/h 25
Flue gas mass ow rate (max) kg/h 558 693 866 1040 1213 1386
Excess air % 24.25
Heat loss at chimney with burner on (min) % 1.5
Heat loss at chimney with burner on (max) % 2.40 2.58 2.53 2.51 2.58 2.58
Minimum heating circuit pressure bar 0.5
Maximum heating circuit pressure bar 6
Water content L 67 67 80 94 108 122
Methane gas consumption G20 (sup.p. 20 mbar) at Qn m
3
/h 36.80 45.68 57.10 68.52 79.94 91.36
Methane gas consumption G20 (sup.p. 20 mbar) at Qmin m
3
/h 2.33
Gas consumption G25 (sup.p. 20/25 mbar) at Qn m
3
/h 42.80 53.13 66.41 79.69 92.97 106.25
Gas consumption G25 (sup.p. 20/25 mbar) at Qmin m
3
/h 2.71
Propane gas consumption (sup.p. 37/50 mbar) at Qn kg/h 27.01 33.53 41.92 50.30 58.68 67.01
Propane gas consumption (sup.p. 37/50 mbar) at Qmin kg/h 1.71
Chimney base maximum pressure available Pa 100
Max condensate production kg/h 59.1 73.4 91.7 110 128.4 146.7
Emissions
CO at maximum heat output with 0% of O2 (PCI) mg/kWh 55 72 76 87 72 76
NOx at maximum heat output with 0% of O2 (PCI) mg/kWh 56 52 52 58 55 57
(***) Sound pressure level dB (A) 54 54 54 54 54 56
Electrical data
Power supply voltage/frequency V/Hz 230 / 50
(**) Protection rating IP X5D
Room Temperature = 20°C
(*) Temperature detected with appliance operation ow 80°C / ret. 60°C
CO
2
(min/max) See ‘’NOZZLES - PRESSURE’’ table
Seasonal Energy E󰀩ciency
according to 2009/125 EEC (<=400Kw) η
s
- see ErP table
Leaks upon stop at ∆T 30°C - Pstb - see
ErP table
Electricity consumption on standby - Psb - see
ErP table
(***) at 1 m away in free eld.
(**) The IP protection rating is obtained with the cover down
2.4 - OPERATING DATA AND GENERAL FEATURES
For the adjustment data: NOZZLES - PRESSURE - COLLECTORS - FLOW RATES refer to the paragraph ADAPTATION TO
OTHER TYPES OF GAS.
