168
Model code
Item
1F1/1F2
MAP1F1A15LV/DV MAP1F1A18LV/DV MAP1F2A25LV/DV
Maximum Travel Speed
Forward mph (km/h) 10.6 (17)
Reverse mph (km/h) 10.6 (17)
Drawbar Pull Maximum Full Load lb (kg / N) 3748 (1700 / 16670)
Truck Weight lb (kg) Refer to Truck Data Plate
Engine
Model K21, GK21
Classication EFI
Rated Output -
SAE Gross
hp (kW) @
rpm
55 (41) @ 2700
Rated Torque - SAE
Gross
ft-lb (Nm) @
rpm
111.4 (151) @ 2000
Displacement cu in (cm) 126 (2065)
Transmission
Type Automatic
Number Speeds - fwd/rev 1/1
